Applications:
The Ventilator is newly developed portable unit, suitable for respiratory management of full anesthestic condition. Light, small, movable, for patient of more than 10 kgs. It can work together with anesthesitic ventilation system and perform tightly closed, semi-tightly closed and semi-open respiratory management.
| Portable Ventilator Main Specifications | |
|---|---|
| Driven mode | Pneumatically driven electronically controlled |
| Display | High light LED display |
| Ventilation Volume | 50 ~ 1600ml |
| Breath frequency | 1 ~ 90BPM |
| I:E ratio | 4:1 ~ 1:6 |
| Monitor parameter | Tidal volume, Breath frequency, MV, Airway pressure |
| Alarm | MV high/low alarm, TV high/low alarm |
| Gas supply | O2 or Air (0.25~0.65Mpa) |
| Physical specification | Packing: 33 x 27 x 41 cm | Gross weight: 8.0kgs |
| Environments | Temp: -9~+35°C | Humidity: 20%~60% | Pressure: 700~1060hPa |
